- ET430 LCR Meter offers 6 test frequencies (100Hz–100kHz) for precise component testing of inductors (L), capacitors (C), and resistors (R). Featuring a 2.8" TFT screen with dual 5-digit readings, it delivers 0.3% basic accuracy and supports electrolytic capacitor testing, Z/X/D/Q/θ/ESR parameters, and fast refresh rates (up to 4 readings/sec). Ideal for electronics repair, PCB testing, and quality control.
- Engineered for efficiency, the ET430 includes open/short calibration and a component sorting mode (1%–50% tolerance). Its deviation measurement compares values against preset standards, while adjustable test levels (0.3V/0.6V) ensure versatility for capacitors, inductors, and resistors up to 20,000mF/2000H/20MΩ. Perfect for labs, factories, and field technicians.
- Compact and rugged, the ET430 features a high-capacity lithium battery, backlit TFT display, and USB communication for data transfer. With multi-language support and auto-shutdown settings, it’s optimized for on-the-go testing of passive components in automotive, power systems, and consumer electronics.
- Designed for speed, the ET430 provides 1–4 readings/second across broad ranges: 0.0001Ω–20MΩ (R), 0.000pF–20,000mF (C), and 0.000µH–2000H (L). Its electrolytic capacitor mode and no internal bias ensure reliable testing of power supplies, motor drives, and industrial equipment.
- Simplify quality checks with the ET430’s 1%-50% sorting limits and intuitive TFT menu. Test L/C/R/Z with 5-digit resolution, adjust brightness, and enjoy plug-and-play operation using included accessories (USB cable, probes, battery). A must-have for engineers and hobbyists.
The ET430 Handheld LCR Meter is a versatile and portable tool designed for precise measurement of inductors (L), capacitors (C), and resistors (R). With 6 test frequencies (100Hz–100kHz) and 0.3% basic accuracy, it ensures reliable testing for components like electrolytic capacitors, coils, and resistors across wide ranges (0.0001Ω–20MΩ, 0.000pF–20,000mF, 0.000µH–2000H). Its 2.8" TFT display shows dual 5-digit readings, while features like open/short calibration, component sorting, and deviation analysis enhance efficiency. Compact, user-friendly, and equipped with USB connectivity and a long-lasting battery, the ET430 is ideal for electronics repair, quality control, and field maintenance.
- Package Dimensions : 7.28 x 3.66 x 1.85 inches; 1.43 Pounds
- Batteries : 1 Lithium Polymer batteries required. (included)
- Date First Available : March 7, 2025
- Manufacturer : yisitai
- Country of Origin : China
