Product description ET43 series handheld bridge features 2.8” TFT display screen, easy key operation and USB communication. Its high capacity lithium battery ensures long run. It can measure comprehensive parameters, and supports for screening and deviation measurement, with continuously adjustable output frequency. The basic accuracy reaches 0.2%.Model: ET433 inductance meter Test frequency: 100Hz~100KHz, continuously adjustable, 1Hz step inductance meter Basic accuracy: 0.2%Display: 2.8" TFT LCD screen inductance meter Display digits: Main parameter: 5 digits Sub-parameter: 5 digits inductance meter Measurement parameters: Main parameters: L/C/R/ZSub-parameters: X/D/Q/θ/ESRElectrolytic capacitor mode: yesDCR mode: yesMeasuring range: L: 0.000µH～2000H, C: 0.000pF～20.000mF, R: 0.0001Ω～20.000MΩMeasurement display speed: 1 time/s (slow), 2 times/s (medium), 4 times/s (fast)Internal Bias: NoneTest level: 0.01~1.1V adjustable, 1mV stepCalibration function: open circuit calibration, short circuit calibrationScreening function: The screening limit range can be set from 1% to 50%, of which the fixed points are 1%, 5%, 10%, 20�viation measurement: used to compare the deviation percentage between the original and the set value and displayOthers: Adjust the brightness of the backlight, the automatic shutdown time can be set, Chinese and English can be selected, USB communicationStandard configuration: 1. Mini-USB cable; 2. Power adapter; 3. Short circuit bar;4. Red and black rubber plug; 5. High capacity lithium battery 6.Kelvin clips

• Package Dimensions ‏ : ‎ 10.43 x 8.5 x 2.68 inches; 1.98 Pounds
• Batteries ‏ : ‎ 1 Lithium Ion batteries required. (included)
• Date First Available ‏ : ‎ March 7, 2022
• Manufacturer ‏ : ‎ zhongchuang
• Country of Origin ‏ : ‎ China
