• Main frame – 2x3” 11-gauge oval tubular steel with a combination of 2x2” round tubing.
• All welded construction by inert-gas MIG welding conforming with all Structural Welding Code-Steel Standards and Specifications.
• Eight-step electrostatically applied powder coat finish.
• Main frame: Platinum Sparkle Accent: Cathedral Gray
• Durable high density pads upholstered in two-tone (Black & Cadet) premium grade, double-stitched naugahyde.
• High density 2” thick rebond urethane foam glued to 1” industrial plywood backing, trimmed and formed to exact fit.
• 1/2” push-pull spring loaded solid steel adjustment pins with ultimate load of 9040 lbs. and 46042 psi sheer strength.
• 1” solid steel pivot axles with non-friction 2” sealed bearings (load rating of 2400 lbs.) internally encased on primary pivots, and oil-impregnated bronze bushings on all secondary pivots.
• 3/4” solid steel 1045 (tgp) polished chrome-plated finish.
• 3/16” and 1/8” USA-Made/Certified EXERFLEX PRO® high performance fitness cable.
• 4-1/2” and 3-1/2” fiberglass-impregnated nylon pulleys with double sealed roller bearings.
• Solid steel, magnetic with ball-end to ensure a tight connection and secure fit. Coiled lanyard helps prevent pin removal and loss.
• All frame bolts and nuts are 3/8” and 1/2” zinc plated.
• Black painted solid steel weight plates with self aligning low friction sleeves.
• Length x Width x Height: 85 x 49 x 84 in/216 x 124 x 213 cm
• Weight: 550 lb/249 kg
